Adding Custom Endpoints to NUXP

A step-by-step guide for adding your own HTTP endpoints to the NUXP plugin. Time estimate: 15 minutes.

Overview

NUXP uses a routes.json configuration file to generate both C++ handler declarations and TypeScript client functions. The workflow is:

1. Define the route once in codegen/src/config/routes.json
2. Run codegen to produce C++ declarations, HTTP wiring, and a typed TypeScript client
3. Implement only the C++ handler body (the business logic)

The codegen guarantees that parameter names, types, and HTTP methods stay in sync between the C++ plugin and the TypeScript frontend. You never manually register an HTTP route or write a fetch wrapper.

---

Step 1: Define the Route

Open codegen/src/config/routes.json and add a new entry to the routes array.

Example: We want an endpoint that returns the number of artboards in the current document.

{
  "name": "GetArtboardCount",
  "method": "GET",
  "path": "/api/artboard/count",
  "description": "Get the number of artboards in the current document.",
  "response": {
    "count": { "type": "number", "description": "Number of artboards" }
  }
}

Add this object inside the existing routes array:

{
  "namespace": "NUXP",
  "routes": [
    // ... existing routes ...

    {
      "name": "GetArtboardCount",
      "method": "GET",
      "path": "/api/artboard/count",
      "description": "Get the number of artboards in the current document.",
      "response": {
        "count": { "type": "number", "description": "Number of artboards" }
      }
    }
  ]
}

Route Field Reference

Field	Required	Description
name	Yes	Identifier used for the C++ handler name (Handle{Name}) and TypeScript function name. Use PascalCase.
method	Yes	HTTP method: "GET", "POST", "PUT", "DELETE", or "PATCH"
path	Yes	URL path. Use {param} placeholders for path parameters (e.g. /api/art/{id}/style).
description	No	Documentation string. Appears in generated code comments.
pathParams	Only if path has {param}	Object mapping each path parameter name to its type definition.
request	No	Request body fields (for POST/PUT/PATCH). Each field has type, optional description, and optional optional: true.
response	No	Response fields. Used to generate TypeScript interfaces.
rawBody	No	When true, body is passed as-is instead of being mapped to named fields. Cannot coexist with request.

Supported Field Types

Type in JSON	C++ Type	TypeScript Type
"string"	std::string	string
"number"	double	number
"boolean"	bool	boolean
"number[]"	std::vector<double>	number[]
"string[]"	std::vector<std::string>	string[]
"object"	nlohmann::json	Record<string, unknown>

More Examples

POST with request body:

{
  "name": "RenameLayer",
  "method": "POST",
  "path": "/api/layer/rename",
  "description": "Rename a layer by index.",
  "request": {
    "index": { "type": "number", "description": "Layer index (0-based)" },
    "name": { "type": "string", "description": "New layer name" }
  },
  "response": {
    "success": { "type": "boolean" }
  }
}

GET with path parameter:

{
  "name": "GetArtBounds",
  "method": "GET",
  "path": "/api/art/{id}/bounds",
  "pathParams": {
    "id": { "type": "string", "description": "Art handle ID" }
  },
  "response": {
    "left": { "type": "number" },
    "top": { "type": "number" },
    "right": { "type": "number" },
    "bottom": { "type": "number" }
  }
}

POST with path parameter AND body:

This produces a handler signature with two parameters: HandleSetArtName(const std::string& id, const std::string& body).

{
  "name": "SetArtName",
  "method": "POST",
  "path": "/api/art/{id}/name",
  "pathParams": {
    "id": { "type": "string", "description": "Art handle ID" }
  },
  "request": {
    "name": { "type": "string", "description": "New name for the art object" }
  },
  "response": {
    "success": { "type": "boolean" }
  }
}

---

Step 2: Run Code Generation

From the codegen directory:

cd codegen && npm run generate

Or from the plugin build directory (if you already have a CMake build configured):

cd plugin && cmake --build build -t generate

Or use the full pipeline script which also copies files to their target directories:

./scripts/generate.sh

What Gets Generated

Three files are updated:

File	Purpose
plugin/src/endpoints/generated/CustomRouteHandlers.h	Adds the C++ function declaration
plugin/src/endpoints/generated/CustomRouteRegistration.cpp	Wires the HTTP route to your handler
shell/src/sdk/generated/customRoutes.ts	Adds a typed TypeScript client function

For our GetArtboardCount example, the codegen produces:

In CustomRouteHandlers.h – the declaration you must implement:

/**
 * GET /api/artboard/count - Get the number of artboards in the current document.
 * @returns JSON: { count: number }
 */
std::string HandleGetArtboardCount();

In CustomRouteRegistration.cpp – the HTTP wiring (you never edit this):

// GET /api/artboard/count - Get the number of artboards in the current document.
HttpServer::Get("/api/artboard/count", [](const std::string&) {
    return HandleGetArtboardCount();
});

In customRoutes.ts – the TypeScript client:

export interface GetArtboardCountResponse {
  /** Number of artboards */
  count: number;
}

export async function GetArtboardCount(): Promise<GetArtboardCountResponse> {
  return fetchRoute<GetArtboardCountResponse>('GET', getApiUrl('/api/artboard/count'));
}

Handler Signature Rules

The codegen determines the C++ function signature from the route definition:

Route Characteristics	Generated C++ Signature
GET, no path params	std::string HandleFoo()
POST with body	std::string HandleFoo(const std::string& body)
Path params only, no body	std::string HandleFoo(const std::string& id)
Path params + body	std::string HandleFoo(const std::string& id, const std::string& body)

---

Step 3: Implement the Handler

Create your handler implementation in a .cpp file inside plugin/src/endpoints/handwritten/. You can add it to the existing NUXPHandlers.cpp or create a new file – the choice is yours.

Here is the complete, working implementation for GetArtboardCount:

// In plugin/src/endpoints/handwritten/NUXPHandlers.cpp
// (or a new file like plugin/src/endpoints/handwritten/ArtboardHandlers.cpp)

#include "CustomRouteHandlers.h"
#include "IllustratorSDK.h"
#include "SuitePointers.hpp"
#include "MainThreadDispatch.hpp"
#include <nlohmann/json.hpp>

using json = nlohmann::json;

namespace NUXP {

std::string HandleGetArtboardCount() {
    json result = MainThreadDispatch::Run([]() -> json {
        // 1. Check that the required suite is available
        if (!SuitePointers::AIArtboard()) {
            return {{"success", false},
                    {"error", "AIArtboard suite not available"}};
        }

        // 2. Get the artboard list
        ai::ArtboardList artboardList;
        ASErr err = SuitePointers::AIArtboard()->GetArtboardList(artboardList);
        if (err != kNoErr) {
            return {{"success", false},
                    {"error", "Failed to get artboard list"},
                    {"errorCode", static_cast<int>(err)}};
        }

        // 3. Get the count
        ai::ArtboardID count = 0;
        SuitePointers::AIArtboard()->GetCount(artboardList, count);

        // 4. Clean up SDK resources
        SuitePointers::AIArtboard()->ReleaseArtboardList(artboardList);

        // 5. Return JSON result
        return {{"count", static_cast<int>(count)}};
    });
    return result.dump();
}

} // namespace NUXP

Critical Pattern: MainThreadDispatch::Run()

Every handler that calls the Adobe SDK must wrap those calls in MainThreadDispatch::Run(). This is non-negotiable.

Why: The HTTP server runs on a background thread, but all Adobe Illustrator SDK calls must execute on the main thread. MainThreadDispatch::Run() queues your lambda onto the main thread (via AITimerSuite callbacks) and blocks the HTTP thread until the work completes.

json result = MainThreadDispatch::Run([]() -> json {
    // Everything inside this lambda runs on Illustrator's main thread.
    // SDK calls are safe here.
    return {{"key", "value"}};
});
return result.dump();  // Back on HTTP thread -- convert JSON to string

If you skip MainThreadDispatch::Run(), your SDK calls will execute on the HTTP thread and crash Illustrator.

Error Handling Pattern

Follow the pattern used throughout NUXPHandlers.cpp:

1. Check suite availability before calling any SDK function
2. Check ASErr return codes after every SDK call
3. Return structured errors with success: false, an error message, and optionally errorCode
4. Clean up SDK resources (release artboard lists, dispose handles, free memory blocks)

if (!SuitePointers::AILayer()) {
    return {{"success", false},
            {"error", "AILayer suite not available"}};
}

ASErr err = SuitePointers::AILayer()->CountLayers(&count);
if (err != kNoErr) {
    return {{"success", false},
            {"error", "CountLayers failed"},
            {"errorCode", static_cast<int>(err)}};
}

POST Handler Example (with request body)

For a POST endpoint, the handler receives the request body as a JSON string. Parse it, validate required fields, then pass data into the MainThreadDispatch::Run() lambda:

std::string HandleRenameLayer(const std::string& body) {
    // Parse the JSON body
    json params;
    try {
        params = json::parse(body);
    } catch (const json::parse_error& e) {
        return json{{"success", false},
                    {"error", std::string("Invalid JSON: ") + e.what()}}.dump();
    }

    // Validate required fields
    if (!params.contains("index") || !params.contains("name")) {
        return json{{"success", false},
                    {"error", "Missing required fields: index, name"}}.dump();
    }

    // Run SDK calls on main thread
    json result = MainThreadDispatch::Run([&params]() -> json {
        if (!SuitePointers::AILayer()) {
            return {{"success", false},
                    {"error", "AILayer suite not available"}};
        }

        ai::int32 index = params["index"].get<int>();
        std::string newName = params["name"].get<std::string>();

        AILayerHandle layer = nullptr;
        ASErr err = SuitePointers::AILayer()->GetNthLayer(index, &layer);
        if (err != kNoErr || !layer) {
            return {{"success", false},
                    {"error", "Layer not found at index"}};
        }

        ai::UnicodeString nameUni(newName);
        err = SuitePointers::AILayer()->SetLayerTitle(layer, nameUni);
        if (err != kNoErr) {
            return {{"success", false},
                    {"error", "SetLayerTitle failed"},
                    {"errorCode", static_cast<int>(err)}};
        }

        return {{"success", true}};
    });
    return result.dump();
}

Path Parameter Handler Example

For routes with {id} in the path, the extracted parameter is passed as a const std::string& argument. Typically you parse it to an integer handle ID:

std::string HandleGetArtBounds(const std::string& id) {
    int artId;
    try {
        artId = std::stoi(id);
    } catch (...) {
        return json{{"success", false},
                    {"error", "Invalid art handle ID"}}.dump();
    }

    json result = MainThreadDispatch::Run([artId]() -> json {
        AIArtHandle art = HandleManager::art.Get(artId);
        if (!art) {
            return {{"success", false},
                    {"error", "Invalid or stale art handle"}};
        }

        AIRealRect bounds;
        ASErr err = SuitePointers::AIArt()->GetArtBounds(art, &bounds);
        if (err != kNoErr) {
            return {{"success", false},
                    {"error", "GetArtBounds failed"},
                    {"errorCode", static_cast<int>(err)}};
        }

        return {{"left", bounds.left},
                {"top", bounds.top},
                {"right", bounds.right},
                {"bottom", bounds.bottom}};
    });
    return result.dump();
}

Including Your New File in CMake

If you added a new .cpp file (rather than appending to NUXPHandlers.cpp), make sure it is included in the build. Files in plugin/src/endpoints/handwritten/ should already be picked up by the CMake glob in plugin/CMakeLists.txt. If not, add it explicitly:

# In plugin/CMakeLists.txt, in the source file list:
src/endpoints/handwritten/ArtboardHandlers.cpp

---

Step 4: Build and Test

Build the plugin:

cd plugin && cmake -B build && cmake --build build

If this is an incremental change (no new files), just:

cd plugin && cmake --build build

Restart Illustrator so it loads the updated .aip plugin, then test from the frontend:

import { GetArtboardCount } from '@/sdk/generated/customRoutes'

const result = await GetArtboardCount()
console.log(result.count)  // e.g. 3

Or test directly with curl:

curl http://localhost:8080/api/artboard/count
# => {"count":3}

---

Quick Reference: Full Route JSON Schema

{
  "name": "RouteName",
  "description": "What this route does",
  "method": "GET | POST | PUT | DELETE | PATCH",
  "path": "/api/your/path/{optionalParam}",
  "pathParams": {
    "optionalParam": {
      "type": "string",
      "pattern": "[a-zA-Z0-9_.-]+",
      "description": "Parameter description"
    }
  },
  "request": {
    "fieldName": {
      "type": "string | number | boolean | number[] | string[] | object",
      "description": "Field description",
      "optional": true,
      "enum": ["allowed", "values"]
    }
  },
  "response": {
    "fieldName": {
      "type": "string | number | boolean | number[] | string[] | object",
      "description": "Field description"
    }
  },
  "rawBody": false
}

Validation rules enforced by codegen:

• Every {param} in path must have a matching key in pathParams
• rawBody: true and request cannot coexist on the same route
• No duplicate route names across the config
• No duplicate method + path combinations

---

When NOT to Use Custom Routes

NUXP’s auto-generated SDK wrappers already cover 442+ functions across all standard Illustrator suites. If you just need to call a single SDK function (get a property, set a value), check shell/src/sdk/generated/ first – it is probably already there.

Custom routes are the right choice when you need:

• Multi-step operations – combining several SDK calls into one atomic request (e.g., GetArtboardCount uses GetArtboardList then GetCount then ReleaseArtboardList)
• Complex data transformations – serializing SDK structs like AIColor (a tagged union with 7 variants) into clean JSON
• Collection iteration – walking the art tree, iterating layers, gathering matching objects
• Aggregated queries – returning document info that pulls from 3-4 different suites in one call
• Special error handling – operations that need cleanup logic, retries, or fallback behavior
• Custom business logic – anything that does not map 1:1 to a single SDK function

If your endpoint just wraps SuitePointers::SomeSuite()->SomeFunction(arg) and returns the result, the auto-generated wrappers are simpler and require zero hand-written code.
