Overview

NUXP’s codegen generates C++ and TypeScript for SDK suite wrappers from parsed Adobe Illustrator SDK headers. But plugin developers also need custom higher-level endpoints that compose multiple SDK calls – for example, “create a planting bed” which involves GetSelectedArt, GetArtBounds, SetNote, and SetArtName in sequence. These don’t map 1:1 to any single SDK function.

Without codegen, custom endpoints are maintained by hand in both C++ and TypeScript, which leads to parameter name mismatches (mode vs lod), field name divergence (perimeter_pts vs perimeter_m), and silent runtime bugs that only surface during integration testing.

Custom route codegen solves this by adding a third input to the pipeline – routes.json – alongside SDK headers and events.json. A CustomRouteGenerator reads this spec and produces three files:

Generated File	Purpose
`CustomRouteRegistration.cpp`	`HttpServer::Get/Post/Delete` route wiring
`CustomRouteHandlers.h`	Handler function declarations (developer implements these)
`customRoutes.ts`	Typed TypeScript client functions

The developer only writes handler implementations. Route paths, parameter names, response types, and HTTP methods all come from the spec.

Configuration: `routes.json`

Location: codegen/src/config/routes.json

{
  "extends": "./base-routes.json",
  "namespace": "MyPluginHandlers",
  "routes": [
    {
      "name": "createBed",
      "description": "Creates a bed from the current selection",
      "method": "POST",
      "path": "/beds/create",
      "request": {
        "bedId": { "type": "string", "description": "Unique bed identifier" },
        "bedName": { "type": "string", "description": "Display name", "optional": true }
      },
      "response": {
        "success": { "type": "boolean", "description": "Whether creation succeeded" },
        "bedId": { "type": "string", "description": "The created bed's UUID" },
        "area_sqm": { "type": "number", "description": "Bed area in square meters" }
      }
    },
    {
      "name": "deleteBed",
      "description": "Deletes a bed by its ID",
      "method": "DELETE",
      "path": "/beds/{id}",
      "pathParams": {
        "id": { "type": "string", "pattern": "[a-zA-Z0-9_-]+", "description": "Bed identifier" }
      },
      "response": {
        "success": { "type": "boolean" },
        "deleted": { "type": "number" }
      }
    },
    {
      "name": "getDocInfo",
      "description": "Returns document information",
      "method": "GET",
      "path": "/doc/info",
      "response": {
        "name": { "type": "string" },
        "path": { "type": "string" },
        "artboardCount": { "type": "number" }
      }
    }
  ]
}

Top-Level Fields

Field	Type	Required	Description
`extends`	`string`	No	Path to a base `routes.json` to inherit routes from
`namespace`	`string`	No	C++ namespace for handler declarations (default: `"CustomHandlers"`)
`routes`	`Route[]`	Yes	Array of route definitions

Route Fields

Field	Type	Required	Description
`name`	`string`	Yes	camelCase identifier (becomes TS function name and C++ handler name)
`description`	`string`	No	Documentation string
`method`	`string`	Yes	`"GET"`, `"POST"`, `"PUT"`, `"DELETE"`, or `"PATCH"`
`path`	`string`	Yes	URL path, with `{param}` placeholders for path parameters
`pathParams`	`Record<string, Field>`	No	Path parameter definitions. Required if path contains `{param}`
`request`	`Record<string, Field>`	No	Request body fields. Omit for no-body endpoints
`response`	`Record<string, Field>`	No	Response fields (used for TypeScript types only)
`rawBody`	`boolean`	No	When `true`, body is passed as-is (no JSON field mapping)

Field Properties

Field	Type	Required	Description
`type`	`string`	Yes	`"string"`, `"number"`, `"boolean"`, `"number[]"`, `"string[]"`, `"object"`
`description`	`string`	No	Documentation string
`optional`	`boolean`	No	Whether the field is optional (default: `false`)
`enum`	`string[]`	No	Allowed values (generates TypeScript union type)
`pattern`	`string`	No	Regex character class for path params (default: `"[^/]+"`)

Generated Files

1. C++ Route Registration (`CustomRouteRegistration.cpp`)

Wires each route to the HTTP server. The generator selects between simple and pattern-based registration depending on whether the route has path parameters.

// Auto-generated by NUXP Codegen - DO NOT EDIT
#include "CustomRouteHandlers.h"
#include "HttpServer.hpp"
#include <string>
#include <vector>

void RegisterCustomRoutes() {
    using namespace MyPluginHandlers;

    // POST /beds/create - Creates a bed from the current selection
    HttpServer::Post("/beds/create", [](const std::string& body) {
        return HandleCreateBed(body);
    });

    // DELETE /beds/{id} - Deletes a bed by its ID
    HttpServer::DeleteWithPattern(
        R"(/beds/([a-zA-Z0-9_-]+))",
        [](const std::string& body, const std::vector<std::string>& params) {
            if (params.empty()) {
                return std::string("{\"error\":\"missing_id\"}");
            }
            return HandleDeleteBed(params[0]);
        });

    // GET /doc/info - Returns document information
    HttpServer::Get("/doc/info", [](const std::string&) {
        return HandleGetDocInfo();
    });
}

Pattern route generation: When a route path contains {param} placeholders, the generator:

Replaces each {param} with a regex capture group using the param’s pattern (or [^/]+ by default)
Uses HttpServer::MethodWithPattern instead of HttpServer::Method
Passes captured groups as a std::vector<std::string> to the handler

2. C++ Handler Declarations (`CustomRouteHandlers.h`)

Declares the handler functions that the developer must implement in their own .cpp files.

#pragma once
// Auto-generated by NUXP Codegen - DO NOT EDIT
// Implement these functions in your own .cpp files.

#include <string>

namespace MyPluginHandlers {

/**
 * POST /beds/create - Creates a bed from the current selection
 * @param body JSON: { bedId: string, bedName?: string }
 * @returns JSON: { success: bool, bedId: string, area_sqm: number }
 */
std::string HandleCreateBed(const std::string& body);

/**
 * DELETE /beds/{id} - Deletes a bed by its ID
 * @param id Bed identifier
 * @returns JSON: { success: bool, deleted: number }
 */
std::string HandleDeleteBed(const std::string& id);

/**
 * GET /doc/info - Returns document information
 * @returns JSON: { name: string, path: string, artboardCount: number }
 */
std::string HandleGetDocInfo();

} // namespace MyPluginHandlers

Handler signature rules – the generator determines the C++ function signature from the route definition:

Route Characteristics	Generated C++ Signature
GET, no path params	`std::string HandleFoo()`
POST/PUT with body (or rawBody)	`std::string HandleFoo(const std::string& body)`
Path params only, no body	`std::string HandleFoo(const std::string& id)`
Path params + body	`std::string HandleFoo(const std::string& id, const std::string& body)`

3. TypeScript Client (`customRoutes.ts`)

Typed client functions with request/response interfaces.

/**
 * Custom Route Client
 * Auto-generated by NUXP Codegen - DO NOT EDIT
 */

import { getApiUrl } from '../config';

// Request/Response Types

/** POST /beds/create - Creates a bed from the current selection */
export interface CreateBedRequest {
  /** Unique bed identifier */
  bedId: string;
  /** Display name */
  bedName?: string;
}

export interface CreateBedResponse {
  /** Whether creation succeeded */
  success: boolean;
  /** The created bed's UUID */
  bedId: string;
  /** Bed area in square meters */
  area_sqm: number;
}

/** DELETE /beds/{id} */
export interface DeleteBedResponse {
  success: boolean;
  deleted: number;
}

/** GET /doc/info */
export interface GetDocInfoResponse {
  name: string;
  path: string;
  artboardCount: number;
}

// Route Functions

/** POST /beds/create - Creates a bed from the current selection */
export async function createBed(params: CreateBedRequest): Promise<CreateBedResponse> {
  return fetchRoute('POST', getApiUrl('/beds/create'), JSON.stringify(params));
}

/** DELETE /beds/{id} - Deletes a bed by its ID */
export async function deleteBed(id: string): Promise<DeleteBedResponse> {
  return fetchRoute('DELETE', getApiUrl(`/beds/${encodeURIComponent(id)}`));
}

/** GET /doc/info - Returns document information */
export async function getDocInfo(): Promise<GetDocInfoResponse> {
  return fetchRoute('GET', getApiUrl('/doc/info'));
}

TypeScript function signature rules:

Route Characteristics	Generated TS Signature
No path params, no request	`functionName(): Promise<Response>`
No path params, has request	`functionName(params: Request): Promise<Response>`
Path params, no request	`functionName(param1: string, ...): Promise<Response>`
Path params + request	`functionName(param1: string, ..., params: Request): Promise<Response>`
rawBody (any)	`functionName(...pathParams, body: string): Promise<Response>`

Usage: Adding a New Route

Step 1: Define the route in `routes.json`

{
  "name": "getPlantInfo",
  "description": "Returns metadata for a plant by UUID",
  "method": "GET",
  "path": "/plant/{uuid}/info",
  "pathParams": {
    "uuid": { "type": "string", "pattern": "[a-f0-9-]+", "description": "Plant UUID" }
  },
  "response": {
    "uuid": { "type": "string" },
    "scientificName": { "type": "string" },
    "commonName": { "type": "string" },
    "spreadDiameter": { "type": "number" }
  }
}

Step 2: Run codegen

npm run generate

This produces updated CustomRouteRegistration.cpp, CustomRouteHandlers.h, and customRoutes.ts.

Step 3: Implement the C++ handler

Create (or update) your own .cpp file – codegen never overwrites implementation files:

#include "CustomRouteHandlers.h"

namespace MyPluginHandlers {

std::string HandleGetPlantInfo(const std::string& uuid) {
    return QueueAndWait([uuid]() -> std::string {
        // Your Illustrator SDK logic here
        nlohmann::json result;
        result["uuid"] = uuid;
        result["scientificName"] = "Quercus virginiana";
        result["commonName"] = "Live Oak";
        result["spreadDiameter"] = 12.0;
        return result.dump();
    });
}

} // namespace MyPluginHandlers

Step 4: Use the generated TypeScript client

import { getPlantInfo } from '@/sdk/generated/customRoutes';

const plant = await getPlantInfo('abc-123');
console.log(plant.scientificName); // Fully typed

Config Inheritance (`extends`)

Downstream projects can extend a base config. This follows the same pattern as SSE events.

NUXP base:     codegen/src/config/routes.json        -> { "routes": [] }
Flora extends:  flora-uxp/codegen/config/routes.json  -> { "extends": "...", "routes": [...] }

Merge strategy:

Load the base config recursively (base configs can themselves extend other configs)
Extension routes override base routes with the same name
Extension’s namespace takes precedence over the base’s
Combined result = base routes (minus those overridden) + extension routes

Example:

{
  "extends": "../nuxp/codegen/src/config/routes.json",
  "namespace": "FloraHandlers",
  "routes": [
    {
      "name": "createBed",
      "description": "Flora-specific bed creation",
      "method": "POST",
      "path": "/beds/create",
      "request": { "bedId": { "type": "string" } },
      "response": { "success": { "type": "boolean" } }
    }
  ]
}

If the base defines createBed and the extension also defines createBed, the extension’s definition wins.

Validation Rules

The generator validates the config on load and throws on any violation:

Each route must have name, method, and path
method must be one of GET, POST, PUT, DELETE, PATCH
Every {param} placeholder in path must have a corresponding entry in pathParams
rawBody: true and request cannot coexist on the same route (you get one or the other)
No duplicate route names across all routes (including inherited ones after merge)
No duplicate method + path combinations

Type Mappings

`routes.json` Type	C++ Type	TypeScript Type
`"string"`	`std::string`	`string`
`"number"`	`double`	`number`
`"boolean"`	`bool`	`boolean`
`"number[]"`	`std::vector<double>`	`number[]`
`"string[]"`	`std::vector<std::string>`	`string[]`
`"object"`	`nlohmann::json`	`Record<string, unknown>`

Enum fields generate TypeScript union types:

{ "type": "string", "enum": ["circle", "svg", "symbol"] }

Produces: 'circle' | 'svg' | 'symbol'

Optional fields generate optional TypeScript properties:

{ "type": "string", "optional": true }

Produces: fieldName?: string

Integration with the Codegen Pipeline

Custom route generation is integrated into codegen/src/index.ts and runs after SSE generation and before CMake include generation:

SDK Headers  ->  SuiteParser  ->  CppGenerator + TypeScriptGenerator
events.json  ->  SSEGenerator ->  Events.hpp + events.ts
routes.json  ->  CustomRouteGenerator ->  Registration.cpp + Handlers.h + customRoutes.ts

The integration follows the same pattern as SSE generation:

Resolve the config path: codegen/src/config/routes.json
Check if the file exists with fs.pathExists()
If present, instantiate CustomRouteGenerator and call its three generation methods
Write output files to the C++ and TypeScript output directories
Errors are caught and appended to the errors array (non-fatal to the rest of the pipeline)
If the config file doesn’t exist, generation is silently skipped

No changes are needed to scripts/generate.sh – the existing file copy logic already picks up all .cpp, .h, .hpp, and .ts files from the output directories.

File Layout

codegen/src/
  config/
    events.json          <- SSE events (existing)
    routes.json          <- Custom routes (new)
    type-map.json        <- SDK type mappings (existing)
  generator/
    SSEGenerator.ts      <- SSE codegen (existing, pattern to follow)
    CustomRouteGenerator.ts  <- Custom route codegen (new)
    CppGenerator.ts      <- SDK wrapper codegen (existing)
    TypeScriptGenerator.ts   <- SDK client codegen (existing)
  index.ts               <- Pipeline entry point (modified)

Path Parameter Regex Generation

When a route has pathParams, the generator converts the path template to a C++ regex string:

Path Template	pathParams	Generated Regex
`/plant/{uuid}/display-mode`	`{ uuid: { pattern: "[a-f0-9-]+" } }`	`/plant/([a-f0-9-]+)/display-mode`
`/beds/{id}`	`{ id: { pattern: "[a-zA-Z0-9_-]+" } }`	`/beds/([a-zA-Z0-9_-]+)`
`/items/{id}`	`{ id: {} }`	`/items/([^/]+)`

If no pattern is specified for a path parameter, it defaults to [^/]+ (any non-slash characters).

The HTTP method also changes from HttpServer::Method to HttpServer::MethodWithPattern for pattern routes.

`rawBody` Routes

When rawBody: true is set, the request body is not parsed into named fields. Instead, the entire body string is passed directly to the handler.

{
  "name": "placeBatch",
  "description": "Places multiple plants from a JSON array",
  "method": "POST",
  "path": "/plant/place-batch",
  "rawBody": true,
  "response": {
    "success": { "type": "boolean" },
    "placed": { "type": "number" }
  }
}

C++ side: Handler receives const std::string& body containing the raw JSON
TypeScript side: Function accepts body: string instead of a typed params object

This is useful for endpoints that accept arrays, complex nested objects, or formats that don’t map cleanly to flat field definitions.

Custom Routes Codegen Spec

Not UXP — Build Illustrator plugins with any JS framework and the C++ SDK

Custom Route Code Generation Specification

Overview

Configuration: `routes.json`

Top-Level Fields

Route Fields

Field Properties

Generated Files

1. C++ Route Registration (`CustomRouteRegistration.cpp`)

2. C++ Handler Declarations (`CustomRouteHandlers.h`)

3. TypeScript Client (`customRoutes.ts`)

Usage: Adding a New Route

Step 1: Define the route in `routes.json`

Step 2: Run codegen

Step 3: Implement the C++ handler

Step 4: Use the generated TypeScript client

Config Inheritance (`extends`)

Validation Rules

Type Mappings

Integration with the Codegen Pipeline

File Layout

Path Parameter Regex Generation

`rawBody` Routes

Custom Route Code Generation Specification

Overview

Configuration: routes.json

Top-Level Fields

Route Fields

Field Properties

Generated Files

1. C++ Route Registration (CustomRouteRegistration.cpp)

2. C++ Handler Declarations (CustomRouteHandlers.h)

3. TypeScript Client (customRoutes.ts)

Usage: Adding a New Route

Step 1: Define the route in routes.json

Step 2: Run codegen

Step 3: Implement the C++ handler

Step 4: Use the generated TypeScript client

Config Inheritance (extends)

Validation Rules

Type Mappings

Integration with the Codegen Pipeline

File Layout

Path Parameter Regex Generation

rawBody Routes

Configuration: `routes.json`

1. C++ Route Registration (`CustomRouteRegistration.cpp`)

2. C++ Handler Declarations (`CustomRouteHandlers.h`)

3. TypeScript Client (`customRoutes.ts`)

Step 1: Define the route in `routes.json`

Config Inheritance (`extends`)

`rawBody` Routes
